The LiftMaster 98022 is a wall-mounted jackshaft opener that frees up the ceiling and handles tall, heavy doors. Mounts on the wall beside the door and drives the torsion shaft directly, so there is no rail across the ceiling.
Specifications at a Glance
Key Features
- Mounts on the wall beside the door and drives the torsion shaft directly, so there is no rail across the ceiling
- Lifts sectional doors up to 850 lbs and 14 ft high
- No cable tension monitor, for easier installation
- Nearly silent and vibration-free operation
- Remote LED lighting, expandable with up to sixteen 827LM remote lights
- Battery backup keeps the door working in a power outage
- Automatic garage door lock deadbolts the door each time it closes
Will This Opener Work With My Door?
- Your door is a sectional residential garage door critical
- The door is balanced: released from the opener, it stays put when lifted halfway critical
- Your door uses a torsion spring system with a torsion shaft critical
- There is enough wall space beside the door to mount the opener
- There is a power outlet near the opener location
Not sure? Tell us your door size and setup and we will confirm the right opener and rail.
Full Technical Specifications
| Brand and model | LiftMaster 98022 |
|---|---|
| Series | Premium Series |
| Drive type | Wall mount (jackshaft) |
| Motor | DC |
| Battery backup | Yes, 485LM |
| Rail | Not required, wall mount |
| Category | Garage door openers |
What’s Included
In the box
- LiftMaster 98022 wall mount opener
- myQ remote LED light (827LM)
- 485LM integrated backup battery
- Automatic garage door lock (841LM)
- 3-button remote control (893MAX)
- Smart Control Panel (880LMW)
Sold separately
- Extra remotes and keypads, see controls
- Replacement battery: LiftMaster 485LM battery
Safety: Test the Safety Reversal After Installation
A garage door opener moves a heavy door, and its safety systems need to be set up and tested correctly.
- Make sure the door is properly balanced before connecting an opener. An opener is not designed to lift an unbalanced door.
- Install the photo-eye safety sensors no higher than 6 inches above the floor.
- After installation, test the safety reversal: the door must reverse when it meets an object on the floor.
- Keep remotes away from children and never let anyone walk under a moving door.
Follow the LiftMaster installation manual, or have a garage door technician install the opener.
Frequently Asked Questions
What is a wall mount (jackshaft) opener?
Instead of hanging from the ceiling and pulling the door along a rail, a jackshaft opener mounts on the wall beside the door and turns the torsion shaft directly. It frees the ceiling for storage or a lift, and suits tall doors and garages with limited headroom.
What does my garage need for a wall mount opener?
A sectional door with a torsion spring system and torsion shaft, and enough side room beside the door to mount the unit. Check the LiftMaster installation manual for the exact clearances for your door.
Does it work during a power outage?
Yes. The included 485LM backup battery lets you open and close the door when the power is out. Replace the battery every few years to keep it reliable.
Can I add more remotes or a keypad?
Yes. See our LiftMaster remotes, keypads and wall controls. Check that the accessory supports your opener’s security protocol before ordering.
Do I need professional installation?
Many owners install their own opener, but the door must be balanced first and the safety reversal must be tested afterward. If your springs or cables need work, have a technician handle that part.
How is it shipped?
It ships by FedEx, or you can collect it from our Sacramento or Santa Clara store. See our shipping policy for current rates and dispatch times.
Why Choose the LiftMaster 98022
LiftMaster is one of the most widely installed opener brands in the US, and the 98022 brings lifts sectional doors up to 850 lbs and 14 ft high, no cable tension monitor, nearly silent and vibration-free operation together in one unit, backed by a LiftMaster warranty.
Contact us if you would like help choosing between openers or rails.
